Any Good Opencv Or Skimage Techniques To Thin Out Gridlines?

I have extracted a clean grid pattern: This above is the grid before I 'skeletonize' (or thin, or perform the medial axis transform). An below is the image after an application of

Solution 1:

I have modified @Miki's answer (actually my search revealed that it was originally posted by another SO user in 2013). See if this solution is something that you could modify, by maybe tweaking a few parameters, to work for your case.

oElem = cv2.getStructuringElement(cv2.MORPH_RECT,(10,1))
h = cv2.morphologyEx(img, cv2.MORPH_OPEN, oElem,  iterations = 5)

oElem = cv2.getStructuringElement(cv2.MORPH_RECT,(1,10))
v = cv2.morphologyEx(img, cv2.MORPH_OPEN, oElem,  iterations = 5)

size = np.size(img)
skelh = np.zeros(img.shape,np.uint8)
skelv = np.zeros(img.shape,np.uint8)

ret,img = cv2.threshold(img,127,255,0)
element = cv2.getStructuringElement(cv2.MORPH_CROSS,(3,3))
done = False
while( not done):
    eroded = cv2.erode(h,element)
    temp = cv2.dilate(eroded,element)
    temp = cv2.subtract(h,temp)
    skelh = cv2.bitwise_or(skelh,temp)
    h = eroded.copy()

    if cv2.countNonZero(h)==0:
        done = True

done = False
while( not done):
    eroded = cv2.erode(v,element)
    temp = cv2.dilate(eroded,element)
    temp = cv2.subtract(v,temp)
    skelv = cv2.bitwise_or(skelv,temp)
    v = eroded.copy()

    if cv2.countNonZero(v)==0:
        done = True

skel = cv2.bitwise_or(skelh,skelv)
